Description
High-pressure rear-tank kit compatible with BinTac T50, BinTac S45, AEA Element Max, AEA Terminator 2 and AEA Megalodon. 7000 PSI fill pressure with an adjustable regulator output from 1500–4500 PSI to deliver consistent, stable full-power shots.
Key Features
- 7000 PSI rated fill pressure for increased shot count and consistent power
- Regulated output adjustable 1500–4500 PSI
- Combined air capacity: 450 CC
- Rear-tank configuration for improved balance and recoil stability
- Precision regulator for consistent shot-to-shot velocity
- High-strength, pressure-rated plumbing and fittings
- Compatible with standard fill nipples used by BinTac/A EA platforms
- Quick-disconnect or integrated fill option (specify during ordering)
Technical Specifications
- Fill Pressure (max): 7000 PSI (482.6 bar)
- Regulated Output Range: 1500–4500 PSI (103.4–310.3 bar)
- Combined Air Capacity: 450 CC
- Material: High-strength aluminum alloy tanks, stainless steel regulator internals, high-pressure-rated HP hose
- Fittings: 7000 PSI-rated fill nipple and output fittings (thread spec: specify per model e.g., 1/8" BSP / NPT as required)
- Operating Temperature: -20°C to 60°C (-4°F to 140°F)
- Weight: (approx.) depends on configuration — typical rear tank + regulator assembly ~600–900 g (estimate; specify if exact required)
- Certification: Pressure-tested to applicable high-pressure standards (hydro test recommended per local regulations)
Compatibility
- BinTac T50
- BinTac S45
- AEA Element Max
- AEA Megalodon
- AEA Terminator 2
Fill Source AEA 480 bar / 7000 PSI Air Compressor
7000 PSI FILL PROBE
